Technical data
Temperature range(℃): -40 to 70
Velocity ratio(%): 69
Characteristic impedance: 100±15 Ohm
Bending radius (min.): 8 x cable diameter
Flame retardancy: CMP, CMR, CMG, CM
UL file number is E334179
Standards and performances
IEC 61156-5 Edition 2.0
EN 50288-3-1
EIA/TIA 568-B.2 – Cat 5e
ISO 11801 Edition 2 – CLASS D
EN 50173 Edition 2 – CLASS D
