Technical data
Temperature range(℃): -40 to 70
Velocity ratio(%): 78
Characteristic impedance:
(From 1 to 250 MHz)100±15 Ohm
(From 250 to 500 MHz)100±20 Ohm
Bending radius (min.): 8 x cable diameter
Flame retardancy: CMP, CMR, CMG, CM
UL file number is E334179
Standards and performances
IEC 61156-5 ed.2.0
ISO/IEC 11801 ed 2.1 Class Ea
TIA/EIA 568-B.2-10 (500 MHz)
