Technical data
Temperature range(℃): -20 to 70
Velocity ratio(%): 66
Linear resistance (max.): <154 Ohm/km
Mutual capacity (nom.): 42 pF/m
Characteristic impedance:
(From 1 to 100 MHz)100±15 Ohm
(From 100 to 250 MHz)100±20 Ohm
Bending radius (min.): 8 x cable diameter
Flame retardancy: CMP, CMR, CMG, CM
UL file number is E334179
Standards and performances
CABLE: - IEC 61156-6
- EN 50288-6-2
SYSTEM: - EIA/TIA 568-B.2-1 CAT6
- ISO 11801 Edition 2 - CLASS D
- EN 50173 Edition 2 – CLASS D
Features and benefits
Exceeds CAT6 standard specifications
To be used for CAT6 patch cords
Available in different colors on request
Network applications
ISDN - VoIP
TOKEN RING 4/16 Mbits - 100 VG-AnyLAN
TP-PMD/TP-DDI - ATM 155, 622,1200 Mbits
ETHERNET: 10 Base T, 100 Base Tx,
100 Base T4, 1000 Base T
