Technical data
Temperature range(℃): -40 to 80
Velocity ratio(%): 66
Characteristic impedance:
(From 1 to 100 MHz)100±15 Ohm
(From 100 to 600 MHz)100±20 Ohm
Bending radius (min.):8 x cable diameter
Flame retardancy: IEC 60332-1
Standards and performances
EN 50288-4-1
IEC 61156-5
EN 50173 Edition 2 – CLASS F
ISO 11801 Edition 2 – CLASS F
