Application
The cable is mainly designed to connect telephone equipments and can be used in low level signaling applications. It is suitable for indoor installation.
Technical data
Temperature rating: 70 ℃
Minimum bending radius
10 x cable diameter
Maximum conductor resistance at 20 °C
96 Ohm/km
Nominal diameter of conductors
0.5 mm
Maximum capacitance unbalance
500 pF/500m
Cable structure
Conductor: solid plain copper
Insulation: SR-PVC
Separator: tape
Sheath: PVC/LSF
Sheath color: white/black
